[:lv]Rane Four[:]

Apraksts

[:lv]https://youtu.be/xDi_Nd2Lg4Q

RANE has produced the ultimate DJ setup, in collaboration with Serato, providing superior Stems control.

Fusing the renowned industrial-grade build and sound quality of RANE hardware with the powerful new Stems capabilities of Serato DJ software, ensures the RANE FOUR will always be by your side, no matter the battle.

Harness The Power of STEMS

The most advanced Serato Stems DJ controller with dedicated Stems pad mode, independent Acapella/Instrumental buttons, and exclusive STEM-SPLIT feature for the ultimate Stems workflow and experience

Focus On Your Performance, Not Your Laptop

The 8 OLED displays above the 16 Performance Pads offer visual feedback for all pad modes. See Cue, Loop, Sample names, Roll and Loop lengths, beat divisions, Pitch Play tuning, Stem elements and FX

Creative Performance Features

Add flavor to your individual Stems and tracks with the 22 hardware Main FX and 4 knob-controlled Channel FX like Reverb, Scale Down Echo, Recycler, Riser, Filter, Filter Roll, Noise, Flanger and more

Four Channels of Performance Possibility

4-Channel mixer with full EQ control, intuitive FX assignment, enhanced Sampler routing and quick-access jog wheel deck selection buttons and 2 external Line/Phono ins for external turntables or decks

Tech Specs:

Digital Audio

Converters: Cirrus Logic, 24-bit PCM, 48 kHz
Digital Signal Processing: 32-bit, Floating Point, Double precisio
Dynamic Range (A-weighted, unity gain):

• ADC: 113 dB
• DAC: 113 dB
• CD Input to Analog Output: 110 dB
• CD Input to USB Output: 113 dB
• USB Input to Analog Output: 113 dB

Inputs

Microphone 1/2 (Combo XLR/1/4″ [6.35 mm] TRS):

• Analog Gain: 25 dB
• Maximum Input: 110 mV
• Gain Trim: Off to +26 dB (unity at center)
• Tone Control: 2-band
• Line/Phono Inputs 3/4 (RCA stereo pairs, switchable):

Line: Line

• Maximum Input: 4 Vrms
• Gain Trim: Off to +12 dB
• Tone Control: 3-band, full-cut to +10 dB
• THD+N (20 kHz BW @ 1 kHz: 0.004%

Phono: RIAA

• RIAA Curve: +/-0.25 dB
• Gain (@ 1 kHz): 31.5 dB
• Maximum Input (@ 1 kHz): 106 mV
• Dynamic Range (A-weighted): 102 dB

Outputs

Main Outputs (XLR):

• Gain Trim: Off to 0 dB
• Maximum Output: 8 Vrms
• THD+N (20 kHz BW @ 1 kHz): 0.004%
• Frequency Response: Flat – 20-20kHz

Main Outputs (RCA stereo pair):

• Maximum Output: 4 Vrms
• THD+N (20 kHz BW @ 1 kHz): 0.004%
• Frequency Response: Flat – 20-20kHz

Booth Outputs (1/4”):

• Gain Trim: Off to 0 dB
• Maximum Output: 8 Vrms
• THD+N (20 kHz BW @ 1 kHz): 0.004%
• Frequency Response: Flat – 20-20kHz

Headphone Outputs (1/4″/6.35 mm and 1/8″/3.5 mm TRS):

• Maximum Output: 4 Vrms Voltage: (no load)
• Output Power: 50 mW (50 ohms)
• Dynamic Range (A-weighted): 108 dB

Pads
(16) on/off multi-color back-lit pads (8 per deck, 9 modes each

Wheel Displays
(2) 320 x 240 Color LCD’s

Pad & FX Displays
(9) 128 x 32 Monochrome OLED’s

Faders
(1) MAG FOUR tension-adjustable crossfader with contour
(4) Standard channel faders

Connections

(2) XLR outputs (Main)
(2) 1/4” outputs (Booth)
(1) RCA stereo output pair (Main)
(2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)
(2) RCA stereo input pairs (Deck 3-4)
(1) 1/4” (6.35 mm) TRS output (Headphones)
(1) 1/8” (3.5 mm) TRS output (Headphones)
(2) USB Type-B ports
(1) IEC power cable input

Power

Connection: IEC
Voltage: 100–240 V, 50/60 Hz
Consumption: 20 W

Dimensions

Dimensions (width x depth x height): 30.8” x 15.9” x 4.2”
782.32 x 403.8 x 106.6 mm
Weight (including platters)
18.25 lbs.
8.27 kg



More info: RANE FOUR[:]
